The tank body adopts advanced butt welding technology. After the tank body is formed, the high-pressure gas leak test makes the tank body have the characteristics of high strength, stable center of gravity, and safe and stable vehicle transportation.
Uses can choose centrifugal pumps, gear pumps, copper core gear pumps, stainless steel pumps, 3 axle acid tanker trailer supplier special pumps, with the characteristics of large flow and fast suction speed. Edible oil can be measured with an edible oil computer meter.
The tank body adopts advanced butt welding technology. After the tank body is formed, the high-pressure gas leak test is used to make the tank body have the characteristics of high strength, stable center of gravity, and safe and stable vehicle transportation.
Uses can choose centrifugal pumps, gear pumps, copper core gear pumps, stainless steel pumps, and concentrated sulfuric acid semi trailers. The ammonia truck supplier's special pump has the characteristics of large flow and fast suction speed. Edible oil can be measured with an edible oil computer meter.
Acid tanker trailer (hydrochloric acid tanker, sulfuric acid tanker, liquid caustic tanker, ammonia tanker) will have to work for several years and travel hundreds of thousands of kilometers from leaving the factory to scrapping. During this period, not only the acid tanker trailer is working for us, we also need our service to ensure the good working condition of the chemical liquid tanker.
1. Maintenance work. Fastening, lubrication, general adjustment, disassembly and cleaning, and replacement of wear parts.
2. Repair work. Troubleshoot, re-adjust, partially dismantle and repair, and replace damaged parts.
3. Overhaul operations. Overhaul the 23cbm acid tanker trailer, replace worn parts, change the size or shape of the parts to restore the fit relationship.
There is no clear boundary between these three types of tasks. With the advancement of technology, their respective contents are constantly changing. Generally speaking, maintenance operations are mostly done by drivers and authorized warranty factories.
The overhaul work must be done by a professional repair shop. There is no fixed model for repair work, which can be undertaken by a repair shop or a few skilled repairmen, supplemented by work benches and instruments to complete the work.
1. The top steel lined plastic manhole is convenient and practical. Aksu paint in the hoarding is beautiful and anticorrosive. Fully plastic threaded manhole cover meets a variety of needs
2. The discharge port at the rear of the tanker: DN100 stainless steel lined PTFE subsea valve + 80 PTFE ball valve + PTFE fast interface is safe, convenient, beautiful and practical. The discharge port protection box is made of one-time injection molding, which is corrosion-resistant and practical.
3. There is a steel diamond mesh connecting layer between the steel plate and the plastic layer of the steel lined plastic tank to ensure the close combination of the plastic layer and the steel plate and reduce the plastic layer shelling caused by thermal expansion and contraction. A double-layer steel-lined plastic anti-wave board is installed in the transport tank.
The material of the side and rear lower guards is Q235B. The side rear guards and the Acid tanker trailer are all welded and bolted. The cross-sectional dimension of the rear guard is 120mm×60mm, and the height of the rear guard from the ground is 500 mm.
A tractor with a speed limit device is used, and the fender style is optional. The outer insulation skin can be galvanized sheet, color-coated sheet, and FRP; the insulation method can be riveted by rivets, and can be tied with insulation tape. The top can be a water retaining groove, or It can be a walking type. Optional ladder front and junction box location.
You can learn about different types of fuel tanker semi trailers (like 3 axle fuel tanker, 4 axle storage tanker trailer, stainless steel tanker trailer, acid tanker trailer, fuel tanker with flatbed trailer, fuel tank Full trailer). And the process, testing, packaging and customer feedback, etc.
