TITAN 4 axle 150 ton lowboy gooseneck with dolly trailer price for transport excavator and construction equipment, large machinery transportation.
Lowboy Gooseneck Trailer for Sale
Lowboy Gooseneck Trailer for Sale
Lowboy Gooseneck Trailer for Sale
Overall dimension：17900mm * 2500+250*2mm *2200mm(platform 800mm)
Loading capacity: 150 ton
Axles：4 axles with 2 axles dolly
Tire: 16 units, 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension
Spring leaf: 120(W)mmx16(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Tare weight: About 9.5-19T
Main beam: Height: 500mm; Width: 230mm; Side beam: 250 I-beam 10/8/10; Material: HG60 high-strength steel.
Bottom Platform: 5mm thick, checkered plate
Hydraulic cylinder: 12KW diesel engine with hydraulic station
Ramp: spring or hydraulic type
ABS: Optional
Valve: WABCO valve
Light: LED light (specially intended for oversea markets)
Voltage: 24V
Tool box: 1 set
Painting: Polyurethane paint, with long service lift, and avoid the vehicle get rust
