In this month, place an order will present quick-spare parts valued at 500 dollars for free!
Definitely! We can discuss the practicable plan and produce it at your request.
1. Timesaving and improve efficiency: TITAN container side loader can be productive all day, enabling loading, unloading and transporting containers by itself easily.
2. Flexible solutions: With the TITAN 37 tons container side loader trailer, you get closer and can lift between trailers safely and with high precision.
3. Famous WABCO braking valve, JOST landing gear for the main chassis container skeleton trailer
4. Famous NBB Germany Remote Control, easy to operate
5. TITAN 40ft container side loader adopts wireless remote control technology, loading container just takes 10 mins.
Drawing of 40Ft Container Side Loader Trailer
Max. lifting capacity: 37/40/45Ton
Max.stabilizer outreach: 3200mm
Max.working range: 4000mm
Overall height: 2500mm
Overall length: 1020mm
Max.pressure of hydraulic system: 28Mpa
Dimension(L*W*H): 14100*2500*4200mm/7500*2500*4200mm
Axle: 3/2axle* 13 ton (220mm brake pads)
Tire: 12/8pcs, 12R22.5
Suspension: Heavy duty type mechanical spring suspension
Kingpin: 3.5 inch bolted type
Braking system: WABCO Emergency valve
Landing gear: JOST
Tow Chain: lgus (imported)
Power source: Power take-off (equipped)
Hydraulic pump: Gear type Casappa Italy
Direction control valves: AMCA Holand
Remote Control: NBB Germany
TITAN container side loader are becoming more and more popular. container side loader trailer are designed to increase various productivity. You will be able to reduce transportation costs, increase profits and have a competitive advantage.TITAN container side loader includes 20ft container side loader trailer, 20ft and 40ft container sideloader. Shipping tonnage is 16tons self unloading container trailer, 37/40/45 ton container side loader for sale, 25tons self loading container truck, 20/40ft side loader for sale for your choice.
