TITAN 40 ft flatbed trailer is made of high strengh carbon steel, which made the flatbed trailer has large capacity and a longer service life. TTIAN 40 ft flatbed trailer is mainly designed for transporting containers, and this method of transportation saves on packaging costs: since the goods are loaded directly in the container, no flipping is required. Therefore, there is no need to package the goods separately, saving packaging costs.
Flatbed Trailer Prices | 40 Ft Flatbed Trailer For Sale Near me Manufacturers
Flatbed Trailer Prices | 40 Ft Flatbed Trailer For Sale Near me Manufacturers
Flatbed Trailer Prices | 40 Ft Flatbed Trailer For Sale Near me Manufacturers
Dimension(mm): 12500x2500x1550mm
Loading capacity(ton): ≤60T
Axles: 4 axles, 13T/16T ,FUWA/ BPW/ TITAN Brand
Tire: 16 units, 12.00R22.5 or 315/80R22.5
Rim: 9.00-22.5 or 9.75-22.5
Suspension: Mechanical suspension
Spring Leaf: 90(W)mmx13(Thickness)mmx10 layers or 100mmx12mmx12 (specially intended for overseas markets)
King Pin: JOST brand 2.0 or 3.5 inch (bolted or welded)
Landing Gear: JOST brand D200T or Chinese brand 28tons(double-speed)
Main Beam: Height: 500mm, Upper plate:14mm, Middle plate:8mm, Bottom plate:16mm, Material:Q345B steel
Side Beam: 16mm or 18mm steel channel (material: Q235 steel)
Platform: 3mm-thick checkered plate
Brake Chamber: WABCO RE 6 relay valve; T30/30+T30 spring brake chamber(TKL brand), 45L air tank
Twist Locks: 4,8,12 sets (lifting or screw type)
Valve: WABCO valve (specially intended for oversea market)
ABS: Optional
Light: LED light (specially intended for oversea market)
Voltage: 24V
Socket(Receptacle): 7-pin Socket (for 7 wire harness)
Tool Box: 1m x 0.5m x 0.5m (The tool box contains 1 tire spanner, 1 gudgeon sleeve and 1 cranking bar. Its size can be tailored to suit your needs)
Painting: Sandblasted, anti-rust chassis surface is available with 1 layer of anticorrosive primer and 2 layers of top coats
TITAN adopts high strength steel material to manufacture the semi trailers, it can make the semi trailer have a higher loading capacity and a longer service life.
TITAN adopts the polyurethane paint for all of the trailers which has high adhesion, more beautiful color, and it will not fall off after more than five years using.
TITAN use the reinforced suspension on the trailers, 70mm king pin. The suspension is reinforced front and rear, left and right, which can better cope with complex road conditions.
Through this videos, you can learn about different types of flatbed semi-trailers, as well as the process, testing, packaging and customer feedback, etc.
