TITAN 40 ton hydraulic tipper trailer has reasonable structure, reliable performance, convenient operation and beautiful appearance. Reasonable structure, strong rigidity and high strength, used to support the load and reduce the impact. At the same time, The hydraulic tipper trailer has more light weight, it has the anti-deformation, anti-vibration and anti-collision capabilities, which are are guaranteed to meet the bearing capacity of different road conditions in Africa.
40 Ton Hydraulic Tipper Trailer Price for Sale Near me | New Tipper Price in Nigeria
40 Ton Hydraulic Tipper Trailer Price for Sale Near me | New Tipper Price in Nigeria
Dimension: 9300mm * 2500mm *1600mm
Main beam: Height: 480mm-500mm, Upper plate: 16mm-25mm, Middle plate: 12mm-20mm, Lower plate: 18mm-25mm
Total volume(m³): 40 ton
Side wall thickness: 4 - 6mm
End plate: 8mm
Lifting System: Full set of HYVA lifting cylinder
Axle: 13T/16T, FUWA / BPW / TITAN Brand
Rim: 8.0-20 or 9.00-20
Tire: 8.25R20/10.00R20/11.00R20/12R22.5
Suspension: Mechanical suspension
Spring leaf: 90(W)mmx13(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Landing gear: JOST brand
TITAN is using HG60 high-strength steel, high hardness of steel, which can effectively prevent collision and avoid deformation of the cargo box; TITAN adopts 4 units vice beams, which can make the bottom of the box body better bearing capacity, and will not easily deform. The lattice structure of the side door makes the side door more solid.
Through these videos, you can learn about different types of tipper semi trailer, as well as the process, testing, packaging and customer feedback, etc.
