That durable and stronger construction ensure the Lowbed Trailer loading capacity, and also improve its capacity to twisting forces, shock, bump, and meet load requirements on bad road condition.
All of TITAN Lowbed trailer for Sale is tested to ensure that our heavy load trailer is free of problems. All Lowbed Trailer for Sale with Dolly Trailer is tested for carrying capacity after production is finished.TITAN has dedicated technical staff to guide the operation.
Overall dimension: 13000mm * 3000mm *3400mm
Loading capacity(T): 40-100T
Axle: 13T/16T, FUWA / BPW / TITAN Brand
Rim: 8.0-20
Tire: 11.00R20
Suspension: Mechanical suspension
Spring leaf: 90(W)mmx13(Thickness)mmx10 layers
Kingpin: JOST brand 2.0 or 3.5inch(bolted or welded type)
Landing gear: JOST brand
Main beam: Height: 500mm, Upper plate: 20mm, Middle plate: 12mm, Lower plate: 20mm, Material: Q345B steel.
Bottom Platform: 5mm thick checkered plate
Ramp: hydraulic type
Gooseneck: Optional
ABS: Optional
Valve: WABCO valve
Light: LED light (specially intended for oversea markets)
